Item No. ● BOPP-SiOx-TZ
Specification |
|
●Thickness: 18μmic ; Width and Length can be customized. |
|
Properties |
|
· ● Excellent barrier properties against oxygen and water vapor. · ● Transparency visibility and print-ability. · ● Retort-ability at 121°C for 30 mins. · ● Two side corona. |
|
Application: ● Work as a barrier layer in flexible packaging lamination structure. ● Recommend structure: BOPP//BOPP SiOx//RCPP. |
|
Material：BOPP-SiOx-TZ（Retort-able and print-ability） |
Size：18µm |
||||
|
Retort condition at 121°C for 30 mins. |
|||||
|
Test item |
Standard |
Test Result |
Result |
||
|
Size deviation |
Thickness（µm） |
18 |
18.1 |
Qualified |
|
|
Thickness deviation（%） |
±10 |
5 |
Qualified |
||
|
Width deviation（mm） |
±2 |
0 |
Qualified |
||
|
Tensile strength （MPa） |
MD |
≥100 |
110 |
Qualified |
|
|
TD |
≥170 |
238 |
Qualified |
||
|
Elongation at break (%) |
MD |
≥140 |
186 |
Qualified |
|
|
TD |
≥30 |
41 |
Qualified |
||
|
Wet tension/ CORONA （mN/m） |
SiOx side |
≥36 |
38 |
Qualified |
|
|
BOPP side |
≥36 |
36 |
Qualified |
||
|
SiOx layer thickness（Ω/口） |
Grade 1 |
Grade 1 |
Grade 1 |
||
|
Uniformity of SiOx layer（%） |
±10 |
2 |
Qualified |
||
|
OTR（cc/㎡.day)（ASTM D 3985） |
≤0.5 |
0.35 |
Qualified |
||
|
WVTR（g/㎡.day)（ASTM F 1249） |
≤0.5 |
0.42 |
Qualified |
||
Technical data sheet
PS: OTR test condition: ASTM D-3985, 23℃,0%RH; WVTR test condition: ASTM F-1249, 38℃,90%RH
